CUB CADET XT2-GX54 D 14B7A6TMA10

SET UP AND PREP FEES MAY APPLY
A strong 25 HP Kohler engine delivers reliable power to tackle your yard.
54-in. heavy-duty fabricated AeroForce™ deck cutting system that has been tested and proven to deliver a best-in-class cut, meaning fewer clumps and stragglers, finer clippings and increased evenness.
AGM battery delivers reliable starting with slower discharge so you worry less about your battery going dead in the offseason.
Rear diff lock ensures your wheels will spin at the same speed, making it easier to navigate difficult terrain.
Engine
Engine Brand: Kohler
Engine Model: KT726
Engine Displacement: 747cc
Engine Output: 26 HP
Fuel Tank Capacity: 3 gal. US (11.35 L)
Cylinders/Material: 2/Cast-iron sleeve
Engine Start: Electric
Engine Oil Capacity: 2 qt US ( 2 L)
Lubrication: Fully-pressurized automotive-style oil pump w/spin-on oil filter
Charging System: Flywheel Alternator – 12 amp regulated
Choke: Separate Choke
Battery
Battery: 12V / 210 cold crank amps
Battery Type : AGM (Absorbent Glass Mat)
Drive System
Transmission: GT Hydro, Foot (TT K62 w/ Diff-Lock) – Steel
Transmission Housing: Cast aluminum
Engine to Transmission: Heavy-duty belt
Rear Differential Lock: Yes
Cutting Deck
Deck Cutting Width: 54-in
Deck Wash: Patented SmartJet™ high-pressure deck washing system
Deck Attach/Removal: QuickAttach™
Blade(s): 3
Deck Lift: Manual
Cutting Height Range: 1″ – 4″
Anti-Scalping: 2 Ball/2 Ball
Deck Positions: 12 Positions
Warranty
Residential Warranty: 3-year Unlimited Hours (Includes Powertrain)
Frame Warranty: 5-year limited warranty
Front Axle Warranty: 5-year limited warranty
Chassis
Frame: Fully robotically-welded frame with new e-coating corrosion defense system
Front Axle: Heavy-duty cast-iron – 5-year limited warranty
Turning Radius: 16-in
Protection: Single-tube
Controls
Cruise Control: Soft touch engagement
Direction: NEW optimized steering system, manual sector and pinion
Brakes: Disc
Comfort
Seat Type: Cub Comfort™ high-back seat with armrests
Seat Adjustment: 10 degree incline and slide
Additional Specifications
Headlight(s): 2 LED High Illumination
Cup Holder: Included
Mulch Kit: optional
Model Number: 14AQA6TMA10
AIR FILTER: 16 883 04-S1
OIL FILTER: 52 050 02-s
ENGINE Oil: 25 357 26-S OR 490-000-C044
TRANS FLUID: TT-187Q0899000
FUEL FILTER: 24 050 13-S1
SPARK PLUG: 25 132 14-S
DECK BELT: 954-05025A
DRIVE BELT: 954-05156A
BLADE: 742P05086 OR 490-110-C194
XTREME BLADE: 742P05086-X OR 490-110-C205
IGNITION KEY: 925-1745A
